SPECIFICATIONS.
Connectivity
| Total Connectors | 1 x 20+4-Pin ATX Motherboard 2 x 4+4-Pin EPS CPU 4 x 6+2-Pin PCIe 8 x 15-Pin SATA 3 x 4-Pin Peripheral / Molex 1 x 4-Pin Floppy |
| Cable Design | Flat, Modular |
| PCIe Connector Distances | 23.6″ / 600 mm 5.9″ / 150 mm |
| SATA Connector Distances | 23.6″ / 600 mm 5.9″ / 150 mm 5.9″ / 150 mm 5.9″ / 150 mm |
| Peripheral Connector Distances | 19.7″ / 500 mm 4.7″ / 120 mm 4.7″ / 120 mm |
| Floppy Connector Distances | 5.9″ / 150 mm |
| ATX Connector Distance | 24″ / 610 mm |
| EPS Connector Distances | 23.6″ / 600 mm |
Electrical
| Total Wattage | 850 W |
| Number of +12 V Rails | 1 |
| Combined Power for +12 V | 850 W |
| Max Load for +12 V | 70.8 A |
| Combined Power for +3.3/+5 V | 105 W |
| Max Load for +3.3 V | 20 A |
| Max Load for +5 V | 20 A |
| Max Power for +5 Vsb | 15 W |
| Max Load for +5 Vsb | 3 A |
| Max Power for -12 V | 3.6 W |
| Max Load for -12 V | 0.3 A |
| Peak Power | 850 W |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz at 12 to 6 A |
General
| Efficiency Rating | 80 PLUS Gold |
| Active Power Factor Correction | No |
| Efficiency | 90% |
| Hold up Time | 16 ms |
| Power-Good Signal | 100 to 150 ms |
Cooling
| Fan Size | 120 mm |
| Bearing Type | Hydraulic |
Physical
| Form Factor | ATX |
| Compliance | ATX 12 V v2.31 |
| Protection | Over-Current Protection, Over-Power Protection, Over-Temperature Protection, Over-Voltage Protection, Short-Circuit Protection, Under-Voltage Protection |
| Mean Time Between Failures (MTBF) | 100,000 Hours |
| Dimensions | 5.9 x 3.4 x 5.5″ / 150 x 86 x 140 mm |
